Nitrile Rubber Insulation
Nitrile Rubber Insulation is an elastomeric, closed-cell rubber-based insulation material available in sheet and pipe form. It is free from CFCs, halogens (chlorine, bromine) and PVC, making it safe, eco-friendly, and suitable for modern HVAC and refrigeration systems.
Designed for air conditioning, heating, cooling, and cold insulation applications, nitrile rubber offers high thermal insulation value, excellent vapor resistance, and long-term performance against condensation and energy loss.
Applications
- Refrigeration & HVAC systems
- Chillers & chilled water pipelines
- Cold storage tanks & cold rooms
- Cold liquid equipment & piping
- Clean rooms & air conditioning ducts
- Wine tanks & temperature-controlled vessels
Key Advantages
- Excellent thermal insulation performance
- Closed-cell structure prevents condensation
- High vapor diffusion resistance
- Flexible, lightweight & easy to install
- Resistant to moisture, mold & corrosion
Product Forms
- Nitrile Rubber Sheet Rolls
- Nitrile Rubber Pipe Sections
- Multiple thickness options
- Standard & custom roll sizes
- Ideal for indoor & outdoor use
Technical Specifications
| Property | Specification |
|---|---|
| Temperature Range |
Tubes: -165°C to +110°C Sheets: -165°C to +85°C |
| Thermal Conductivity λ W/(m·K) |
≤25 mm: 0.031 @ -20°C → 0.037 @ +40°C >25 mm: 0.034 @ -20°C → 0.040 @ +40°C |
| Corrosion Resistance | pH Neutral (7 ± 0.5) |
| Water Vapor Permeability (μ) | ≥10000 (≤25 mm) | ≥7000 (>25 mm) |
Nitrile Rubber Sheet Roll Specifications
| Thickness (mm) | Roll Size | Sqm / Roll | Unit |
|---|---|---|---|
| 6 | 1.2 m × 30 m | 36.00 | M² / Roll |
| 9 | 1.2 m × 20 m | 24.00 | M² / Roll |
| 13 | 1.2 m × 14 m | 16.80 | M² / Roll |
| 16 | 1.2 m × 12 m | 14.40 | M² / Roll |
| 19 | 1.2 m × 10 m | 12.00 | M² / Roll |
| 25 | 1.2 m × 08 m | 9.60 | M² / Roll |
| 32 | 1.2 m × 06 m | 7.20 | M² / Roll |
| 40 | 1.2 m × 04 m | 4.80 | M² / Roll |
| 50 | 1.2 m × 04 m | 4.80 | M² / Roll |
Why Choose Cabsons Nitrile Rubber Insulation?
Cabsons Insulation Pvt. Ltd. supplies premium-grade nitrile rubber insulation with consistent density, reliable vapor resistance, and dependable availability for HVAC, refrigeration, cold storage, and clean room insulation projects across India.
